Specification

• Rated Voltage: DC7.4V
• Voltage Range: DC6.0V-8.4V
• Working Frequency:  760us/560Hz
• Temperature Range: -10℃……+65℃
• Case Material: Aluminum Alloy
• Motor Type: Brushless DC Motor
• Gear Set Material: Hardened Steel
• Position Sensor: Potentiometer
• Ball Bearing: 2 Ball Bearings
• Case Dimensions: 35.5mm*15mm*35.5mm±0.2mm
• Torque: 1.0N.m@6.0V/ 1.3N.m@7.4V/ 1.5N.m@8.4V
• Speed: 0.07sec/60°@6.0V; 0.06sec/60°@7.4V; 0.05sec/60°@8.4V
• PWM Command Interface
• Weight: 45g±10%
